Case Studies
Cooling Tower FAN Application - 3.7kW x 8 FAN + Siemense PLC and 45 kW VFD
Total 08 Nos of FAN Controlling by Siemense PLC HMI VFD using Manual Mode and Auto Mode. Temperatures Delta T-55 deg. C to 35deg. C- Control, Flow Control, PH Water Control, Flushing System, Energy Consumption, Datalogging, Modbus and Ethernet Communication, Siemense PLC to PLC Communication with Remote Control System.
Project Conveyor Automation with High Temperature Oven 200 degree Controls
Total -154 IO.
Total Power Rating 54 kW Thyristor + 14 kw Blowers + 1 kW Conveyor. Total Load 69kW @ 415VAC, Multiple MCCB, SPP, Shunt Coil, Control ON-OFF, Power Emergency, Total IO safety next generation design till year 2040 with Robot Modbus Communication and SCADA
SPM-OVEN Project Automation with High Temperature Oven 200 degree Controls using Siemense PLC and 10 Inch HMI - with 120DIDO + +4RTD+4AI+4AI-2AO+ 4AO
Total -138 IO.
Total Power Rating 96 kW Thyristor + 14 kw Blowers +
Total Load 110kW @ 415VAC, Multiple MCCB, SPP, Shunt Coil, Control ON-OFF, Power Emergency, Total IO safety next generation design till year 2040 with Etgernet, Modbus Communication
Rain Test Rig - Defense Project Automation with Highest Water Flow, Pressure and Level Control s using Delta PLC and 10 Inch Delta HMI - with 46DIDO + +4RTD+4AI+4AO
Total -56 IO.
Datalogging, VNC Server Computer Datalogging.
Total Power Rating 30 kW VFD + 22 kw High Pressure Pumps +
Total Load 30kW @ 415VAC, Multiple MCCB, SPP, Shunt Coil, Control ON-OFF, Power Emergency, Total IO safety next generation design till year 2040 with Etgernet, Modbus Communication
SPM-ROTARY CONVEYOR Project Automation with Low Temperature 10 degree C Controls using Siemense PLC and 7 Inch HMI - with 46DIDO + +4RTD+4AI+4AI-2AO+ 4AO
Total -62 IO.
Total Power Rating 5.5 kW + 180 Watt x 12 Air Blowers +
Total Load 5.5kW @ 415VAC, Multiple MCCB, SPP, Shunt Coil, Control ON-OFF, Power Emergency, Total IO safety next generation design till year 2040 with Ethernet, Modbus Communication
Hyundai-Motors Chennai passengers CAR Paint Shop-I and Paint Shop-II, Waste Heat Recovery System Automation-in year 2022-23 and 2023-24 Technology with Allen-Bradley PLC, VFD, HMI with 1200 IO, 320 kW Power with Fiberoptic Communication @ 2 km
Total 14 nos of Control Panel's
Waste Heat Recovery System Automation-in year 2022-23 and 2023-24 Technology with Allen-Bradley PLC, VFD, HMI with 1200 IO, 320 kW Power with Fiberoptic Communication @ 2 km
NORMA INDIA PVT. LTD. SPM-OVEN Project Automation with High Temperature Oven 200 degree Controls & LOW TEMP. 10 deg. C, CONTROL using DELTA PLC and 10 Inch HMI - with 1760DIDO + +8RTD+8AI+4+ 8AO
Total -200 IO.
Total Power Rating 125 kW Thyristor + 25 kw Blowers +
Total Load 150kW @ 415VAC, Multiple MCCB, SPP, Shunt Coil, Control ON-OFF, Power Emergency, Total IO safety next generation design with Ethernet, Modbus Communication
